Wildcat XX

Go Anywhere. Ride Over Everything.

Built to handle boldly, corner ruthlessly and dominate the most extreme terrain.

Highlights

Off-Road Racing

Suspension System

Unequal Length

Front A-Arms

Rear

Trailing Arm

Largest-in-Class

Ergonomic Cab

Naturally Aspirated

EFI Engine

2-Passenger

Wildcat XX

A side-by-side ready to take on dirt, dunes, mud and rocks with 130HP and suspension technology rooted in off-road racing.

  • Premium FOX® 2.5 PODIUM QS3 Shocks with Bottom-Out Control
  • 998cc 3-Cylinder Naturally Aspirated EFI Engine with 130 HP
  • 18 Inches of Front and Rear Travel
  • 2WD/4WD with 4WD Lock
  • 14-inch Ground Clearance
Wildcat XX
  • Colors
Off-Road Racing Inspired Suspension System
Unequal Length A-Arm Front Suspension

A better ride starts up front. Our unequal length A-arms neutralize camber, grabbing more of the ground to stabilize you through every white-knuckle corner.

Rear Trailing Arm Suspension

Hardcore trophy truck and Class 1 buggy racers will recognize the vehicle’s rear trailing arm. It links to the front instead of the sides to keep your wheels moving up-and-down, not side-to-side.

80% Less Track-Width Change

Many vehicles are plagued with side-to-side motion that pushes you off course, requiring constant steering corrections and robbing you of stability. Wildcat XX creates 80% less track-width change than the competition for the smoothest ride in the industry.

Premium FOX 2.5 PODIUM QS3 Shocks with Bottom-Out Control
QS3 Dial

When you want to dial in a more precise ride for the obstacle in your way, FOX QS3 technology lets you do it more quickly and more simply than other suspension systems.

Bottom-Out Control

When you hit a little turbulence, a secondary piston engages in the final 30 percent of shock travel, packing an additional 3,000 pounds of damping force.

Durable Components

If you’re thinking of taking it easy on Wildcat XX — don’t. We doubled down on durable, tested parts, including:

  • Double Shear Steering and Suspension Components
  • Forged Aluminum Front Knuckle
  • Oversized Front and Rear Wheel Bearings
  • Hanging Rear Drivetrain
  • Removable Rear Bottom Skid
Easy to Service

Wildcat XX is easier to service than any other performance side-by-side. Toolless bed removal gives you access to the powertrain, and a removable rear bottom skid plate lets you service the transaxle and engine with ease. You can also enter the front gear case by pulling off the front steel skid. All so you can make quick adjustments, then get back in the driver’s seat.

Over 30 Custom-Built Accessories

We made Wildcat XX to take on the most extreme terrain — and you get to make it yours. Customize the ultimate performance side-by-side with 30 premium accessories, including:

  • Bumpers and Guards
  • Cab Accessories
  • Rear Windshields
  • Audio and Speaker Systems
  • Cargo and Racks
  • Lights
  • Roofs
  • Storage
  • Windshields

Vehicle Specs

Wildcat XX
Engine Type Liquid-Cooled, 4-Stroke Inline Triple Cylinder Dual Overhead Cam, Gas Engine
Horsepower 130HP
Displacement 998cc
Drive Train CVT
Drive System Selectable 2WD/4WD
Fuel System Electronic Fuel Injection (EFI)
Gear Selection TEAM Rapid Response Clutches (H,L,N,R,P)
Front Differential Selectable Electronic Locking
Rear Differential Spool
Wildcat XX
Steering Electronic Power Steering with Tilt Steering Wheel with Sport Design
Front Suspension Double A-Arm with 18 in. (45.7 cm) Travel
Rear Suspension Trailing Arm with 18 in. (45.7 cm) Travel
Shock Absorbers FOX 2.5 PODIUM QS3 with Compression Adjustment (Front) FOX 2.5 PODIUM QS3 with Compression Adjustment and Bottom-Out Control (Rear)
Brake System Dual Piston Front Calipers and Single Piston Rear Calipers
Parking Brake Park in Transmission
Tires 30 x 10 x 15 in. CST Behemoth Tires (Front and Rear)
Wheels 15 in. Aluminum KMC Wheels
Wildcat XX
Total Capacity 730 lbs (331.1 kg)
Bed Load Capacity 300 lbs (136.1 kg)
Wildcat XX
Alternator (Electrical Charging System) 470 Watt Stator and 65 Amp Alternator
Accessory Connection System Pre-Wired Connections for up to 8 Accessories (4 Switch & 4 Key-on)
Wildcat XX
Overall Length 136 in. (345.4 cm)
Overall Width 64 in. (162.6 cm)
Overall Height 67.5 in. (171.5 cm) w/o roof | 68 in. (172.7 cm) w/ roof
Overall Weight 1,816 lbs (823.7 kg) (Dry)
Wheelbase 95 in. (241.3 cm)
Ground Clearance 14 in. (35.6 cm)
Fuel Capacity 10 gal (37.9 L)
Glove Box Capacity 4 gal (15.1 L)
Bed Dimensions (L x W x H) 34 x 32 x 9 in. (86.4 x 81.3 x 22.9 cm)
Wildcat XX
Standard Colors Charcoal Metallic/Medium Green, White/Fire Red
Wildcat XX
Instrumentation Dual Screen LCD Gauge with Seatbelt Indicator, High Beam Indicator, Oil Pressure Indicator, Coolant Temp. Warning Light, Check Engine Light, Engine Hour Meter, Odometer & Trip Meter, Clock, Gear Position, Diagnostics
Lighting Low/High Beam Halogen Headlights with LED Accent
Seating Stitched, Two-Tone, Contoured Bucket Seats
Storage Components Cargo Bed, Glove Box, Cup Holders (2)
Additional Features 3-Point Seat Belts (4-Point and Click-6 Ready), Seat Belt Rev Limiter, Standard Full Doors, Race-Inspired ROPS with Front and Rear Intrusion Bars, 2 Passenger Grab Handles, Headlights, Brake Lights
Standard Accessories N/A
