Riot
Built to Handle It All
Why choose between the thrills of on-trail riding and the adventure of venturing into the deep snow when you can have both? Riot blends trail and backcountry performance seamlessly for the ultimate adaptable ride.
Shopping Tools
Riot
Vehicle Specs
Print SpecsEngine
| Riot 600 | Riot 600 with ATAC | RIOT 8000 | RIOT 8000 with ATAC | RIOT 9000 | |
|---|---|---|---|---|---|
|
Engine Type
|
600, 2-Stroke | 600, 2-Stroke | 8000, 2-Stroke | 8000, 2-Stroke | 9000, 4-Stroke |
|
Displacement
|
599cc | 599cc | 794cc | 794cc | 998cc |
|
Cooling
|
Liquid | ||||
|
Cylinders
|
2 | 2 | 2 | 2 | 3-Turbocharged |
|
Bore x Stroke
|
73.8 x 70 mm | 73.8 x 70 mm | 85 x 70 mm | 85 x 70 mm | 80 x 66.2 mm |
|
Lubrication
|
Electronic Injection | Electronic Injection | Electronic Injection | Electronic Injection | Dry Sump |
|
Ignition
|
Digitally Controlled CDI | Digitally Controlled CDI | Digitally Controlled CDI | Digitally Controlled CDI | Digital Controlled Coil Induction |
|
Engine Stator Output
|
270 W @ 3000 RPM | 270 W @ 3000 RPM | 270 W @ 3000 RPM | 270 W @ 3000 RPM | 545 W @ 5000 RPM |
|
Fuel Delivery
|
Dual Stage Injection | Dual Stage Injection | Next-Generation C-TEC2 | Next-Generation C-TEC2 | Electronic Fuel Injected (EFI) |
|
Exhaust
|
APV w/ Tuned Pipe, Pipe Sensor and Stainless Steel Manifold and Muffler | APV w/ Tuned Pipe, Pipe Sensor and Stainless Steel Manifold and Muffler | APV w/ Tuned Pipe, Pipe Sensor and Stainless Steel Manifold and Muffler | APV w/ Tuned Pipe, Pipe Sensor and Stainless Steel Manifold and Muffler | Turbocharger w/ Stainless Steel Muffler |
|
Fuel Capacity
|
10.4 gal | 10.4 gal | 11.7 gal | 11.7 gal | 9.9 gal. |
|
Oil System Capacity
|
3.0 qt. | 3.0 qt. | 3.25 qt. | 3.25 qt. | 3.8 qt. |
|
Coolant System Capacity
|
5.4 qt. | 5.4 qt. | 6.7 qt. | 6.7 qt. | 6.4 qt. |
|
Minimum Octane
|
91 | ||||
Powertrain
| Riot 600 | Riot 600 with ATAC | RIOT 8000 | RIOT 8000 with ATAC | RIOT 9000 | |
|---|---|---|---|---|---|
|
Drive Clutch
|
ADAPT | ||||
|
Driven Clutch
|
ADAPT | ||||
|
Drive System
|
AC Trail Belt Drive | AC Trail Belt Drive | Arctic Drive System | Arctic Drive System | Arctic Drive System |
|
Brakes
|
Stealth Hydraulic Master Cylinder | ||||
|
Clutch Calibration
|
0-5,000 ft. | 0-5,000 ft. | 0-5,000 ft. | 0-5,000 ft. | 0-10,000 ft. |
|
Gearing
|
27/60 | 27/60 | 22/48 | 22/48 | 22/48 |
|
Chain Pitch
|
Belt | Belt | 90 | 90 | 90 |
|
Track Drive Sprocket
|
9 Tooth, Exvolute | 9 Tooth, Exvolute | 9 Tooth, 2.86 Pitch, Exvolute | 9 Tooth, 2.86 Pitch, Exvolute | 9 Tooth, 2.86 Pitch, Exvolute |
|
Reverse
|
Push-Button Engine | ||||
Suspension
| Riot 600 | Riot 600 with ATAC | RIOT 8000 | RIOT 8000 with ATAC | RIOT 9000 | |
|---|---|---|---|---|---|
|
Front Suspension
|
Arctic Wishbone Suspension 39 | Arctic Wishbone Suspension 39 | ARS II | ARS II w/ ATAC | ARS II w/ ATAC |
|
Ski Shocks
|
Arctic Cat IFP 1.5 | FOX 1.5 ZERO iQS | FOX 1.5 ZERO QS3 | FOX 1.5 ZERO iQS | FOX 1.5 ZERO iQS |
|
Sway Bar
|
Standard | ||||
|
Front Travel
|
7.5 in. | 7.5 in. | 9 in. | 9 in. | 9 in. |
|
Rear Suspension
|
CROSS-ACTION w/ 3-Wheel Rear Axle Assembly, Torque-Sensing Link Rear Arm, and Adjustable Torsion Springs | CROSS-ACTION w/ 3-Wheel Rear Axle Assembly, Torque-Sensing Link Rear Arm, Adjustable Torsion Springs, and ATAC System | CROSS-ACTION w/ 3-Wheel Rear Axle Assembly, Torque-Sensing Link Rear Arm, and Adjustable Torsion Springs | CROSS-ACTION w/ 3-Wheel Rear Axle Assembly, Torque-Sensing Link Rear Arm, Adjustable Torsion Springs, and ATAC System | CROSS-ACTION w/ 3-Wheel Rear Axle Assembly, Torque-Sensing Link Rear Arm, Adjustable Torsion Springs, and ATAC System |
|
Front Track Shock
|
Arctic Cat IFP 1.5 | Arctic Cat IFP 1.5 | Arctic Cat IFP 1.5 | Arctic Cat IFP 1.5 | |
|
Rear Track Shock
|
Arctic Cat IFP 2.0 | FOX 2.0 ZERO iQS | FOX 2.0 ZERO QS3 | FOX 2.0 ZERO iQS | FOX 2.0 ZERO iQS |
|
Rear Travel
|
13.5 in. | ||||
Dimensions
| Riot 600 | Riot 600 with ATAC | RIOT 8000 | RIOT 8000 with ATAC | RIOT 9000 | |
|---|---|---|---|---|---|
|
Overall Chassis Length
|
130.5 in. | 130.5 in. | 132 in. | 133 in. | 132 in. |
|
Overall Chassis Width
|
48-49 in. | ||||
|
Overall Chassis Height
|
49 in. | 49 in. | 48 in. | 48 in. | 48 in. |
|
Track Type
|
Cobra or Hurricane | Cobra or Hurricane | Cobra | Cobra | Cobra |
|
Track Width
|
15 in. | ||||
|
Track Length
|
146 in. | ||||
|
Lug
|
1.6 in. or 1.75 in. | 1.6 in. or 1.75 in. | 1.60 in. | 1.60 in. | 1.60 in. |
|
Pitch
|
2.86 in. | ||||
|
Ski Stance
|
38-40 in. Adjustable | 38-40 in. Adjustable | 41.5-43.5 in. Adjustable | 41.5-43.5 in. Adjustable | 41.5-43.5 in. Adjustable |
|
Ski Type/Width
|
G2 ProClimb- 7 in. | ||||
|
Runner Type
|
Single Runner w/ Carbide | ||||
Instrumentation
| Riot 600 | Riot 600 with ATAC | RIOT 8000 | RIOT 8000 with ATAC | RIOT 9000 | |
|---|---|---|---|---|---|
|
Type of Gauge
|
Sport | Deluxe Digital | Deluxe Digital | Deluxe Digital | Deluxe Digital |
|
Speedometer
|
Digital | ||||
|
Tachometer
|
Digital | ||||
|
Odometer
|
Digital | ||||
|
Fuel
|
Digital | ||||
|
Oil
|
LCD Icon | Indicator Light | Indicator Light | Indicator Light | Indicator Light |
|
Coolant
|
Digital Bar Graph | Digital/Indicator Light | Digital/Indicator Light | Digital/Indicator Light | Digital/Indicator Light |
|
Clock
|
N/A | Digital | Digital | Digital | Digital |
|
Battery Voltage
|
N/A | Digital | Digital | Digital | Digital |
|
Altimeter
|
N/A | Digital | Digital | Digital | Digital |
|
Hours
|
Digital | ||||
Features
| Riot 600 | Riot 600 with ATAC | RIOT 8000 | RIOT 8000 with ATAC | RIOT 9000 | |
|---|---|---|---|---|---|
|
Color
|
Sunset Orange or Black | Sunset Orange or Black | Medium Green | Medium Green | Medium Green |
|
Heat Exchanger
|
Front/ Long Tunnel | ||||
|
Starter
|
Electric Push-Button | ||||
|
Handlebars
|
Hooked | ||||
|
Lighting
|
LED | LED | LED w/ Accent Light | LED w/ Accent Light | LED w/ Accent Light |
|
Seating
|
Trail | Trail | Mountain | Mountain | Mountain |
|
Standard Accessories
|
Sway bar, 12v outlet, sport front bumper, goggle holder, hand & thumb warmers, front/long tunnel heat exchanger, ice scratchers, standard brake disc, standard steering, ATACH 4-point latching system, trail seat, tether switch, visor plug-ins | Sway bar, 12v outlet, sport front bumper, goggle holder, hand & thumb warmers, front/long tunnel heat exchanger, ice scratchers, standard brake disc, standard steering, ATACH 4-point latching system, trail seat, tether switch, visor plug-ins | 12V Outlet, Sport Front Bumper, Goggle Holder, Hand & Thumb Warmer, Ice Scratchers, Standard Brake Disc, Standard Steering, Mid-Tunnel Bag, Tether Switch | 12V Outlet, Sport Front Bumper, Goggle Holder, Hand & Thumb Warmer, Ice Scratchers, Standard Brake Disc, Standard Steering, Mid-Tunnel Bag, Tether Switch | 12V Outlet, Sport Front Bumper, Goggle Holder, Hand & Thumb Warmer, Heated Driver's Seat, Ice Scratchers, Standard Brake Disc, Standard Steering, Tether Switch |
|
Windshield
|
6-in. Low-Height | 6-in. Low-Height | 5.5 in. Race-Height | 5.5 in. Race-Height | 5.5 in. Race-Height |
Vehicle specifications are subject to change.
